DXP HD 4K PLUS Series • SIS Configuration and Control 55
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Preset Commands (continued)
Rooms
Set room outputs
EX1*,X@
1
,X@
2
...
X@
n
MR}
MprX1*,X@
1
,...X@
n
]
Set outputs to a room.
n
= desired number
of outputs within the
maximum number.
Example
E7,3,4,7 MR} Mpr7,3,4,7]
Assign outputs 3, 4, and 7
to room 7.
View room outputs
EX1*MR} X@
1
,...X@
n
]
View the outputs of a
room.
Set room name
EX1*,X$ NR} NmrX1*,X$]
Set a room name.
View room name
EX1*NR} X$]
NmrX1*,X$]
View a room name.
Verbose modes 2 and 3
Reset room map
EZR} Zpr]
Clear all room and output
configurations.
Reset individual room
EX1*ZR} ZprX1*]
Clear a room output
configuration.
Room Presets
NOTE:
n
= maximum number of outputs.
Save room preset
X1**X1(, RmmX1*•SprX1(]
Save the current
configuration to a room
preset.
Recall room preset
X1**X1(. RmmX1*•RprX1(]
Apply a room preset
configuration.
Directly write room preset
E+X1**X1(PX!*X@ %... X!*X@ %}
RmmX1*•SprX1(]
Save a specified
configuration in one
command entry (see
Input and Output
Tie Commands
on page48 for
independent tie
commands).
View room HDMI preset
EX1**X1(*01*1VC} X!
1
•X!
2
•...X!
n
•Vid]
View the inputs tied to
each output of a room
preset.
KEY:
X! = Input number
1 through <maximum number of inputs>.
X@ = Output number
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
X$ = Name
16 alphanumeric characters ([unassigned] for presets that have not
been saved)
X1* = Room number
1 through 10
X1( = Room preset number
1 through 10
