DXP HD 4K PLUS Series • SIS Configuration and Control 56
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Preset Commands (continued)
Room Presets (continued)
View room audio preset
EX1**X1(*01*2VC} X!
1
•
X!
2
•
...--X!
n
•
Aud]
View the inputs tied to
each audio output of a
room preset.
-- = output is not
applicable.
Set room preset name
EX1**X1(,X$ NP} NmpX1**X1(,X$]
Define a room preset
name.
View room preset name
EX1**X1( NP} X$]
NmpX1**X1(,X$]
View a room preset name.
Verbose modes 2 and 3
Reset all room presets
EZP} Zpp]
Clear all room preset
configurations.
Reset individual room preset
EX1**X1( ZP} ZppX1**X1(]
Clear a room preset.
Advanced Configuration Commands
Front Panel Lockout Mode (Executive Mode)
Set Front Panel Lockout
mode
X2)X ExeX2)]
Set the accessibility to
front panel operation.
View Front Panel Lockout
mode
X
X2)]
View the accessibility level
for front panel operation.
Video Signal Presence
View video signal presence
status
0LS
X2@
1
X2@
2
...X2@
n
]
Frq00
•
X2@
1
X2@
2
...
X2@
n
]
View the signal presence
status of all inputs.
n
=
maximum number of
inputs.
Verbose modes 2 and 3
KEY:
X! = Input number
1 through <maximum number of inputs>.
X$ = Name
16 alphanumeric characters ([unassigned] for presets that have not
been saved)
X1* = Room number
1 through 10
X1( = Room preset number
1 through 10
X2) = Front Panel Lockout mode
0 = unlock the front panel
1 = mode 1 (complete front panel lockout)
2 = mode 2 (tie configuration and preset management only, default)
X2@ = Video signal status
0 = No signal detected
1 = Input signal detected
