Quantum Series Videowall Processing Systems • Installation and Maintenance 30
NOTE: The breakout cable connected to the bottom connector on the
Video/S-video input card should have only the C cables of S-video devices
attached.
3. Repeat step 2 for any additional S-video devices that you want to connect.
Connector pin assignments
Top connector:
Pin Function Pin Function Pin Function
1 CVBS or Y 1 in 10 Ground 19 CVBS or Y 7 in
2 CVBS or Y 2 in 11 Ground 20 CVBS or Y 8 in
3 CVBS or Y 3 in 12 Ground 21 CVBS or Y 9 in
4 CVBS or Y 4 in 13 Ground 22 CVBS or Y 10 in
5 CVBS or Y 5 in 14 Ground 23 CVBS or Y 11 in
6 CVBS or Y 6 in 15 Ground 24 CVBS or Y 12 in
7 Ground 16 Ground 25 Ground
8 Ground 17 Ground 26 Ground
9 Ground 18 Ground
Bottom connector:
Pin Function Pin Function Pin Function
1 C 1 in 10 Ground 19 C 7 in
2 C 2 in 11 Ground 20 C 8 in
3 C 3 in 12 Ground 21 C 9 in
4 C 4 in 13 Ground 22 C 10 in
5 C 5 in 14 Ground 23 C 11 in
6 C 6 in 15 Ground 24 C 12 in
7 Ground 16 Ground 25 Ground
8 Ground 17 Ground 26 Ground
9 Ground 18 Ground
