Mt 880/870/En/Rev. 002/05/98 * 901.882.002
BEISSBARTH MT 870 / MT 880
1-1
Operating range:
Wheel weight: up to 65kg
Wheel diameter: Passenger cars from 10" to 20"
Light commercials up to 17.5"
Rim width: up to 13.5" (345mm), motorcycles from 2"
Max. outer diameter of wheel: 900mm
Operating temperature range: +5°C to 40°C
Atmospheric humidity range: 10-90% at 40°C
Drive:
Motor: 0.37kW 3X100/173V, with power supply from
internal frequency converter
Mains voltage single-phase 200-240V, frequency 50/60Hz
Balancing speed 192 rpm
Measuring time: 2.5 sec
Braking electric, with additional mechanical brake
to lock the wheel before weights are attached
Noise emissions: LpA value=70 dB (A)
Equipment:
14” VGA colour monitor, resolution 640x480 PC-based computer with CD-ROM drive
Machine
dimensions:
With wheel guard (WxHxD) 1350x1540x1650mm
Weight 130kg
Paint finish: enquiry to Beissbarth
The right to modify designs is reserved.
TECHNICAL DATA
