Mt 880/870/En/Rev. 002/05/98 * 901.882.002
BEISSBARTH MT 870 / MT 880
3-1
Controls and screen buttons
BRIEF DESCRIPTION
Action Center:
The Action Center is used to operate all the system functions. It is turned to the
left/right to locate the desired function, and pressed to activate it.
Patent: US 6.003.367
EP 0728299
Main switch (emergency off):
to switch the machine on and off
Wheel guard:
with electrical interlock (a
legal requirement in
Germany). Balancing can
only take place with the
wheel guard closed.
Sensing arm:
to determine rim width (on
microtec 880)
Position measuring arm:
to determine rim width and attach
adhesive weights
Start
balancing
run
Inner/outer
plane
Enter rim
dimensions
Select
weight
attachment
Free-choice
weight
positioning
Fine
balancing
Switches
the brake
on and off
System
set-up
Special
functions
Display
help text
