Installation manual
CNC 8035
4.
MACHINE PARAMETERS
Ethernet parameters
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·166·
4.7 Ethernet parameters
These parameters may be used to configure the CNC like any other node in the network, the DNC
for Ethernet, the hard disk (KeyCF) and the Ethernet network. Doing that requires the Ethernet
option.
If the CNC is configured like another node in the network, it may be accessed from any PC of the
network knowing its IP. Only the CNC's KeyCF may be accessed; i.e. it is not possible to access
programs in RAM nor read variables, tables, etc.
With the CNC configured in the network, the following is possible from any PC of the network:
• Access the part-program directory of the hard disk (KeyCF).
• Edit, modify, delete, rename, etc., the programs stored on the hard disk (KeyCF).
• Copy programs from the hard disk (KeyCF) to the PC and vice versa.
HDDIR (P0) CNMODE (P1)
Not being used.
CNID (P2)
CNC name when connecting it via FTP (only when allowed by the FTP client).
CNGROUP (P3) . . . CNHDDIR1 (P6)
Not being used.
CNHDPAS1 (P7)
Password for accessing the KeyCF from the network.
EXTNAME2 (P8) . . . SERUNI2 (P21)
Not being used.
Parameters Configuration
Basic configuration:
DIRIP (P24)
NETMASK (P25)
IPGATWAY (P26) (optional)
Configure the CNC like another node in the network. The KeyCF is
accessible via FTP.
Basic configuration and also:
CNHDPAS1 (P7)
Protect the access from the network to the
KeyCF using a password.
Basic configuration and also:
IPWDNC (P27)
Configure the DNC for Ethernet.
Basic configuration and also:
IPSNFS (P28)
DIRNFS (P29)
Configure the
KeyCF.
Possible values
It admits up to a maximum of 15 characters (without blank spaces).
Default value: FAGORCNC
Possible values
It admits up to a maximum of 15 characters (without blank spaces).
