Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIOR-E-48I32O / RIOR-E-48I32O-ANALOG (ETHERCAT).
Power supply for the module.
ꞏ108ꞏ
REF. 2107
6.4.3 External power supply requirements.
24 V DC class III power supply that does not exceed the SELV/PELV limits.
If the supply cable is longer than 10 meters, some protection element must be installed at the input
of the device to protect it against voltage peaks. The power supply must be connected to the
ground/shield of the module for functionality or electromagnetic compatibility; for electromagnetic
compatibility, this connection must only be done at one point.
Nominal voltage.
Meets EN 61131-2 24 V DC
Voltage range (mean value). Within 20.4 V DC and 28.8 V DC.
Voltage range (dynamic). Within 18.5 and 30.2 V DC.
Voltage ripple peak-to-peak. 5% (unfiltered 6-pulse rectification).
Non-periodic over-voltages.
Over-voltage. 35 V
Duration of the over-voltage. 500 ms
Recovery time. 50 s
Events per hour. 10
Transient voltage interruptions.
Idle time. 3 ms
Recovery time. 10 s
Events per hour. 10
