Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
4.
Technical and electrical characteristics.
ꞏ49ꞏ
REF. 2107
4.2 Technical and electrical characteristics.
4.2.1 Technical characteristics.
Mechanical characteristics.
Vibrations (module RIOW-CANOPEN-STAND).
• Meets the IEC60068-2-6 standard.
• Sweep sine trial with a frequency step of 1 octave/minute (±10%) and on each of the three
axes.
Choques.
• Meets the IEC60068-2-27 standard.
• Semi-sinusoidal pulses with 15g peaks for 11 ms. 3 pulses in each direction (positive and
negative) of each of the three vertical axes (18 pulses in all).
Free fall.
• Meets the IEC60068-2-32 standard.
• Up to 1 m with the unit in its original packaging.
Electromagnetic compatibility.
Regulations valid for all RIOW modules.
Immunity against disturbances (regulation EN 50082-2:1996).
• Meets the EN 61000-4-2 regulation.
• Meets the EN 61000-4-3 regulation.
• Meets the EN 61000-4-4 regulation.
• Meets the EN 61000-4-6 regulation.
Regulations valid for all RIOW modules except for RIOW-CANOPEN-STAND module.
Emission of disturbances (regulation EN 50081-1:1993).
• Meets the EN 55022 regulation.
Regulations only valid for RIOW-CANOPEN-STAND module.
Emission of disturbances (regulation EN 50081-2:1994).
• Meets the EN 55011 regulation.
Ambient conditions.
• Relative humidity: 5-95% without condensation.
• Work temperature: 0-55 ºC.
• Storage temperature: Between -20 ºC ( 77 ºF) and +85 ºC (158 ºF).
• Resistance to harmful substances: Meets standards IEC 60068-2-42 and IEC 60068-2-
43.
5 Hz
 f < 9 Hz 1.750 mm amplitude (constant) or 3.5 mm (short periods).
9 Hz
 f < 150 Hz 0.5 mm (constant acceleration) or 1g (short periods).
