RIOR-E-48I32O / RIOR-E-48I32O-ANALOG (ETHERCAT).
Specifications.
ꞏ102ꞏ
REF. 2107
6.1 Specifications.
The machine manufacturer must comply with the EN 60204-1 (IEC-204-1) regulation
regarding electrical shocks in case of defective input/output pins with external power supply
when not plugging the connector before turning the power supply on.
Type. Description.
General. • Remote EtherCAT input and output module.
• Dimensions (width x height x depth)
- 150 × 272 × 36.50 mm.
- 5.90" × 10.70" × 1.44".
Operating
conditions.
• Equipment for indoor use in non-hazardous locations, operated by qualified
personnel skilled in its use.
• The equipment must be installed in an enclosure that meets the
requirements described in this manual.
• Equipment designed for use in fixed locations.
• Equipment not suitable for wet areas.
• Never use in explosive environments (dangerous areas).
Regulations. • It complies with the European directives for electromagnetic compatibility
2014/30/EU and low voltage 2014/35/EU. See the declaration of conformity,
available on our website.
• UL 61010-1 (Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 1: General
Requirements). See the certificate, available on our website.
• IEC/UL 61010-2-201 (Safety requirements for elecrical equipement for
measurement, control and laboratory use. Particular requirements for
control equipment).
• Canadian Standards Associations: CSA C22.2 No. 142 (Process Control
Equipement).
Packaging. • The package meets the regulation EN 60068-2-32 procedure 1 with a
random fall from a height not greater than 1 m.
Ambient. • Storage and transport temperature according to IEC 61131-2:
- Between -40 ºC (-40 ºF) and +70 ºC (158 ºF).
• Work temperature according to IEC 61131-2:
- Between 5 ºC (41 ºF) and 55 ºC (131 ºF).
• Temperature outside cabinet according to IEC 61131-2:
- Between 5 ºC (41 ºF) and 45 ºC (113 ºF).
• Temperature inside the enclosure:
- Less than 55 ºC (131 ºF).
• Relative humidity according to IEC 61131-2:
- 20 ~ 85% RH without condensation.
• Maximum work altitude:
- The unit must work properly at 2000 m according to IEC 61131-2.
• Vibration test according to IEC 60068-2-6 with a frequency step of
1 octave/minute (±10%) and a duration of 10 sweeps.
-5 Hz f 8.4 Hz; movement of constant 3.5 mm amplitude (peak value).
-8.4 Hz f 150 Hz; 1g acceleration and constant amplitude (peak value).
• Degree of protection according to EN 60529:
-IPxx.
• Pollution degree 2 according to IEC/UL 61010-1.
Electrical. • Connection to mains supply: Permanent.
• Operating conditions: Continuous.
• Protection against electric shock: Class III (PE connection is only for
functional earthing).
• OVC I protection level according to IEC/UL 61010-1.
Power supply. • Use a regulated 24 V DC power supply (between -15% and +20%) and 2 A
(including voltage ripple and noise). The power supply must meet the
UL1950 standard.
Connectivity. • 2 ports LAN RJ45, for EtherCAT bus.
