RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
4.
Technical and electrical characteristics.
ꞏ51ꞏ
REF. 2107
4.2.2 Electrical characteristics of the inputs and outputs.
Digital outputs.
All digital outputs have a status indicating LED that turns on when the output is active. The
outputs are protected with opto-couplers and protected against short-circuits.
Digital inputs.
All digital inputs have a status indicating LED that turns on when the input is active. The inputs
are protected by opto-couplers.
Analog inputs.
All analog inputs have a status indicating LED that turns on when there is an over-voltage
or an under-voltage.
Use shielded cables connecting their meshes to the corresponding shield pin. Maximum
cable length (unshielded): 75 mm.
Analog outputs.
Each input has 2 LED's; a green one that turns on when the bus transmission is OK and a
red one that turns on when there is an overload or a short-circuit to ground at any of the
outputs.
Use shielded cables connecting their meshes to the corresponding shield pin. Maximum
cable length (unshielded): 75 mm.
Technical characteristics.
Number of outputs. 8 outputs per module.
Nominal voltage. +24 V DC (between -15 % and +20 %).
Typical consumption. 15 mA per module plus the consumption of the
elements.
Output current. 500 mA per output.
Technical characteristics.
Number of inputs. 8 inputs per module.
Nominal voltage. +24 V DC (between -15 % and +20 %).
Low threshold "0". Within -3 and 5 V DC.
High threshold "1". Within 15 and 30 V DC.
Typical consumption. 2.8 mA.
Technical characteristics.
Number of inputs. 4 inputs per module.
Voltage range. ± 10 V.
Maximum input voltage. ± 40 V.
Typical input impedance. > 100 k
Measuring error (25 ºC). <± 0.1 %
Resolution. 12 bits.
Typical consumption of each input. 0.5 mA.
Technical characteristics.
Number of outputs. 4 outputs per module.
Voltage range. ± 10 V.
Impedance of the connected device. > 5 k
Output filter time (typical value). 100 ms.
Measuring error (25 ºC). <± 0.1 %
Resolution. 12 bits.
Typical consumption of each input. 0.5 mA.
