Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
4.
RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
Technical and electrical characteristics.
ꞏ52ꞏ
REF. 2107
Analog inputs for PT100 temperature sensors.
Each input has 2 LED's; a green one that turns on when the bus transmission is OK and a
red one that turns on when there is a reading error at the inputs.
The inputs are protected by opto-couplers. Use shielded cables connecting their meshes to
the corresponding shield pin. Maximum cable length (unshielded): 75 mm.
Technical characteristics.
Number of inputs. 2 inputs per module.
Type of sensor. PT100
Type of connection. 2-wire or 3-wire interface.
Temperature range. Between -200 ºC ( -328 ºF) and +850 ºC (1562 ºF).
Resolution. 0.1 ºC
Measuring error (25 ºC). <± 0.2 %
Response time, from when the sensor is
connected until the first correct measure is
obtained.
4 s.
Typical consumption of each input. 0.5 mA.
