Fagor CNC 8058elite T User Manual

Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
4.
RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
Dimensions of the modules.
ꞏ48ꞏ
REF. 2107
4.1 Dimensions of the modules.
A2
E2
C
48
15
26
37
C
A
D
B
A3
D
48
15
26
37
C
A
D
B
56781234
ON
STOP
RUN
TX
RX
Overflow
I/O
E2
C
D
E1
mm inch
A2 51 2,01
A3 12 0,47
C 100 3,94
D35 1,38
E1 65 2,56
E2 64 2,52
