Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
3.
RIO5 REMOTE MODULES. (CANOPEN PROTOCOL).
Electrical characteristics of the inputs and outputs.
ꞏ42ꞏ
REF. 2107
3.5 Electrical characteristics of the inputs and outputs.
Digital inputs.
All digital inputs are galvanically isolated through opto-couplers. All the digital inputs have
the following characteristics:
Digital outputs.
All digital outputs are galvanically isolated through opto-couplers. All the digital outputs have
the following characteristics:
The digital outputs have a fuse inside for protection against over-voltage (over 33 V DC) and
against reverse connection of the power supply.
Analog inputs.
Use shielded cables connecting their meshes to the corresponding shield pin. All the analog
inputs have the following characteristics:
Analog outputs.
Use shielded cables connecting their meshes to the corresponding shield pin. All the analog
outputs have the following characteristics:
Inputs for the temperature sensors PT100.
Use shielded cables connecting their meshes to the corresponding shield pin. The electrical
characteristics of the inputs are:
Nominal voltage. +24 V DC (between +18 V DC and +30 V DC).
High threshold "1". Over +18 V DC.
Low threshold "0". Under +9 V DC.
Typical consumption of each input. 5 mA.
Maximum consumption of each input. 7 mA.
Nominal voltage. +24 V DC (between +18 V DC and +30 V DC).
Output voltage. 2 V less than the supply voltage.
Maximum output current. 500 mA per output.
Voltage within range. ± 10 V.
Resolution. 12 bits.
Input impedance. 20 k.
Maximum cable length (unshielded). 75 mm.
Command voltage within range. ± 10 V.
Resolution. 16 bits.
Minimum impedance of the connected device. 10 k.
Maximum cable length (unshielded). 75 mm.
Type of sensor. PT100
Temperature range. Between -200 ºC ( -328 ºF) and +850 ºC (1562 ºF).
Resolution. 0.1 ºC
Typical consumption of each input. 2 mA.
Maximum cable length (unshielded). 75 mm.
