Fagor CNC 8058elite T - 4.6.1 Elements (connectors).

Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
4.
RIOW-PS24 module.
ꞏ69ꞏ
REF. 2107
4.6.1 Elements (connectors).
Power supply.
Status indicator LED's.
The LED is green. The LED turns on if the side jumpers have 24 V.
Signal Function
24 V Power supply.
0 V 0 V reference signal.
GND Ground connection.
48
15
26
37
24 V
0 V
GND
C
A
D
B
24 V
