Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIOR-E-48I32O / RIOR-E-48I32O-ANALOG (ETHERCAT).
Technical/electrical characteristics of the inputs and outputs.
ꞏ114ꞏ
REF. 2107
Inputs for the temperature sensors PT100.
Use shielded cables connecting the shields to the ground plate of the module itself. The
electrical characteristics of the inputs are:
Characteristic. Value.
Type of sensor. Pt100
Temperature range. Between -200 ºC ( -328 ºF) and +850 ºC (1562 ºF).
Resolution. 0.1 ºC
Typical consumption of each input. 1 mA.
Maximum cable length (unshielded). 75 mm.
