POWER-UP SEQUENCE FOR MULTIPLE CONTROLS
Turn on all scoreboards and controls. Scoreboards will lock-on to controls
transmitting in the assigned group number or to the alternate group number.
TWO SCOREBOARDS TO SINGLE CONTROL
Each pair of scoreboard-and-control
was assigned their own group number
from the same scoreboard type.
 Split Mode – turn on both
scoreboards and controllers.
Each scoreboard is controlled
by a control with the matching
group number.
 Single Mode – turn off one of
the controls. The scoreboard
assigned to that group
number will scan and lock on
to the control transmitting the
same scoreboard type.
