MP-73/53 G3 Wireless Option
132 MP-70/50 • MP-72/52 • MP-73/53 • PN 98-0002-29 • REV 1709.13
MULTIPLE COURTS TO SPLIT OR SINGLE CONTROL
Each of the scoreboard and control pairs was assigned their own group number
from the same group.
Split Mode - turn on all scoreboards and controllers. Each scoreboard is
controlled by a controller with the matching group number.
Even Split Mode - turn off controls that were set to odd group
numbers. The scoreboards that are set to odd group numbers will then
scan and lock-on to the remaining controls transmitting in even group
numbers.
Odd Split Mode - turn off controls that were set to even group
numbers. The scoreboards that are set to even group numbers will
scan and lock-on to the remaining controls transmitting in odd group
numbers.
Single Mode – turn off three (3) controls but keep one control on. All
scoreboards will scan for the next available control within their group and
lock-on to the only remaining control that is still transmitting.
