DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 12
.
Step
Procedure
4
Remove one (1) screw (F000178) that attaches the Flipper Module to the Printer.
Detach the cable from J23 on the mainboard.
