DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 45
.
Remove/Replace the Output Roller (D930123) Pinch Roller-spring (D920013-F000338)
Step
Procedure
1
Caution: Turn OFF the Printer and unplug the power cord from the Printer.
2
Remove the Output Roller Gear (D930361) by pulling straight out.
No need to remove the Stepper Motor Assembly.
Tools needed: T10 Torx screwdriver
Estimated Repair Time: 20 min
Preparation: Remove the Covers
Important: This procedure can only be performed by
authorized service personnel.
