DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 33
.
Step
Procedure
4
Slide board out from the corner posts
5
Install new board and reconnect all wires.
Wires are labeled for location connection.
6
Procedure is complete.
