DTC1000Me-1250e-4250e-4500e Card Printer Service Manual PLT-01543 rev 1.0
November 2013 49
.
Step
Procedure
6
Remove the print head assembly if better access is needed.
See Printhead removal procedure Replacing the DTC Printhead.
7
Move the lever up to clear the Platen Roller (D930120)
8
Replace with new roller.
9
Reverse assembly to reinstall parts.
10
Procedure is complete.
