DAZZLER
TM
system manual Part I : installation & operation 5.2
Figure 5.10: Missed triggers due to excessive power
average power to the crystal when the trigger repetition rate is changed outside the software
during the experiment.
Remarks on B & Alternate Use: in these cases of operation, the software chooses the worst
case between A and B.
5.2 Menu bar
5.2.1 File Menu
This menu allows storage and retrieving of waveform parameters (i.e. panel settings). This is
done with the traditional open, save as and save items.
To ease operation, the items save default & restore default. The save default menu is
equivalent as saving settings on exit: it will save the current waveform and the trigger settings.
restore default will only restore the current waveform. Trigger settings cannot be restored
in this way. The information is kept in the parameters directory (section 5.5).
The menu item exit stops the program.
5.2.2 Setup menu
trig and mode opens the Trig&Mode panel, see section 4.2
remote enable enables/disables the response to remote requests, see chapter 6
sequences control (optional) opens the sequences control panel
for Dazzler
TM
models with the ”sequence mode” option
V3.00 - 8
th
April 2019 (ContentsTable) (FiguresTable) 44/94
