DAZZLER
TM
system manual Part I : installation & operation 8.7
8.7.1 Output signal S1
Back panel BNC S1: output of a TTL logic signal which is related to the operation of the
generator, the actual signal to be chosen via a selector with 8 choices, see further. Affectation
of the signals depends of the firmware of the RF board. Changes are required at each generation
of RF boards, the actual lists can be seen in the selectors appearing in the Trig&Mode panel.
8.7.2 Output signal S2
Back panel BNC S2: output, in particular used to generate a self trigger signal: the selection
T1out is forced in internal triggering mode, total of 8 choices, see the implemented signals by
opening the Trig&Mode panel.
8.7.3 Output signal list
extracted from Siegman/PROD/.../DAZZLER/GZ0655.txt
signal usage RF board V5.x
(CHOP and FIFOGATE) triggers/N in streaming sequence
(GATE and (/CHOP)) pulsed triggers (N-1)/N
(GATE and CHOP) pulsed triggers 1/N
/(CHOP) inverted triggers/N
/GATE OFF during RF signal
/GATEBASIG inverted gating signal (option g)
ALTDELSRC alternate delay indicator
AUXCOPY aux input copy
BOARDBUSY memory access
CHOP triggers/N
FIFOCMDSTATE.0 FIFO Transfer Idle
FIFOREP FIFO repetition overflow
FSMPCNT.4 fdata/32
FSMPCNT.5 fdata/64
FSMPDIV4 data sampling clock, divided by 4
GATE ON during RF signal
V3.00 - 8
th
April 2019 (ContentsTable) (FiguresTable) 87/94
