FCI FS10A - FS10 Flow Element Options

FS10 Series
Fluid Components International LLC 11
INTEGRAL CONFIGURATION
WITH STANDARD FLOW ELEMENT
INTEGRAL CONFIGURATION
WITH ADAPTABLE FLOW ELEMENTS
1/2" NPT
FM: 3022666 PLUS
500° RATED ELEMENT
FCI PN 020800
ALL-WELDED
1/2" NPT
WIRE
PIGTAIL
.81 SHOWN
SEE TABLE
FM: 3013994
FLOW SENSOR ASSEMBLY,
1/2, 1 AND 2 INCH SIZES WITH BUTT WELD,
SANITARY FLANGES OR MALE NPT PROCESS CONNECTIONS
3/4" NPT PROCESS CONNECTION
316L SST
FM: 3018600
PROBE ASSEMBLY
FLOW
U
FM: 3023468 PLUS
500° RATED ELEMENT
FCI PN 019348
PRESS-FIT
1/4" NPT
FM: 302346 PLUS
500° RATED ELEMENT8
FCI PN 021145
PRESS-FIT
1/2" NPT
FM: 302266 PLUS
500° RATED ELEMENT6
FCI PN 020000
ALL-WELDED
1/4" NPT
LENGTH VARIABLE
FM: 3035947
FCI PN 021146-XX
PROBE ASSEMBLY WITH PROTECTOR,
ALL-WELDED, 1000 OHM,
ST51/OEM
X
LENGTH
0.65
0.46
TABLE OF AVAILABLE LENGTHS
ADAPTABLE FLOW ELEMENTS
(SPECIAL ORDER)
SWAGELOK FITTING
1/2" OR 3/4" NPT
NPT
SIZE
1/4"
1/2"
U
1.57
1.67
LENGTHS
AVAILABLE
0.81
0.60
1.34
1.34
U
1.90
2.00
2.13
2.13
U
2.64
2.74
WELDED
1/4" NPT
1/2" NPT
PRESS FIT
POTTED
CABLE
1/4" NPT
PRESS FIT
POTTED
CABLE
M12
CONNECTOR
C01036-2-1
A
.61
.95
3.96
.94
.60 U-LENGTH
Ø 1.50
Ø 1.50
Ø 1.13
Ø 1.69
BOOT
TAG
FLOW ELEMENT PORT,
1/2
"-14 NPT
OR 1/4"-18 NPT
FLOW
TRANSMITTER, FT
FLOW
ELEMENT, FE
ACTIVE
SENSOR
REF.
SENSOR
TAG
BOOT
POLYESTER
OVERLAY DECAL
BOOT REMOVED
FOR CLARITY
M12, MALE
8-PIN
POLYESTER
OVERLAY DECAL
BOOT REMOVED
FOR CLARITY
M12, MALE
8-PIN
FS10 Flow Element Options
