FS10 Series
Fluid Components International LLC 29
Time Delay to Activate
Relay after reaching
switch point (sec)
Time Delay to De-activate
Relay after being tripped
(sec)
Flow (0-100%) Analog (4 mA-20 mA)
0 to 100%
Display LEDs
Output and Display Parameters
Figure 4 – FS10 Output and Display Parameters
