FCI FS10A - Installation Dimensions, FS10 Remote Mounting Bracket (025442-01)

FS10 Series
18 Fluid Components International LLC
C01359-1-1
A A
(1.79)
[45.4]
(Ø .18)
[4.5]
(.90)
[22.8]
(.22)
[5.6]
1.66
[42.1]
(Ø1 .69)
[42.9]
(2.34)
[59.4]
5.44
[138.1]
(.98)
[24.9]
(Ø1 . 50)
[38.1]
MOUNTING BRACKET
(025442-01)
SECTION A-A
(ROTATED 90°)
USE #8 or [M4] SECURING SCREW,
LENGTH AS APPROPRIATE FOR
MOUNTING SURFACE
Installation Dimensions, FS10 Remote Mounting Bracket (025442-01)
