FCI FS10A User Manual

FS10 Series
60 Fluid Components International LLC
Relay Output
022474-A02 - 8 pin M12(F) connector with 6 feet [2 meter] pigtail and wire markers
022474-A05 - 8 pin M12(F) connector with 15 feet [5 meter] pigtail and wire markers
022474-A10 - 8 pin M12(F) connector with 30 feet [10 meter] pigtail and wire markers
N-Channel MOSFET Output
022474-B02 - 8 pin M12(F) connector with 6 feet [2 meter] pigtail and wire markers
022474-B05 - 8 pin M12(F) connector with 15 feet [5 meter] pigtail and wire markers
022474-B10 - 8 pin M12(F) connector with 30 feet [10 meter] pigtail and wire markers
Power Only to customer M12 installed connector
(Reference auxiliary drawing C00976 - page 33)
(Reference auxiliary drawing C00978 - page 35)
(Reference auxiliary drawings C00976 and C00977 - pages 33 and 34)
PC Interface Components

FCI FS10A Specifications
