Commissioning
29
–
The positioner is fully mounted and connected.
–
Ensure that the compressed air supply is stable during commissioning.
–
Familiarise yourself with the menu system, the functions of the keys and the parameters prior to
commissioning.
–
è
4.1.3 Operation and display
–
è
7.2 Checking and setting parameters in the menu views
1. Check the operating conditions and critical limits
è
10 Technical data.
2. Check that the connection points are tight.
3.
Switch on the power supply.
4. Switch on the compressed air supply.
5. Check the sensing range of the position sensor.
6.
Set the parameters.
The parameters can also be set with the setup wizard
è
Further information.
7.
Start the initialisation.
The drive moves when the initialisation is started.
If the initialisation fails, approach the two end positions several times in the ‘Manual travel’
operating mode in order to minimise potential sliding friction effects.
7.2
Checking and setting parameters in the menu views
7.2.1 Menu structure of the menu views
The following overview shows all the menus and parameters available in the device in the menu views.
Not all menus and parameters are available for all product variants.
