9 Disassembly
CAUTION
Pressurised lines
Even if the compressed air feed is shut off the pneumatic ports of the positioner may still be under
pressure.
• Exhaust the pneumatic ports (working ports) before disconnecting the hose assemblies.
Disassembling the positioner
1.
Switch off the compressed air supply.
2. Unscrew the 4 housing cover screws.
3. Remove the housing cover.
4.
In the menu views, select manual operation ‘Manual venting’
è
7.2.3.2 ‘Manual venting’ manual
manipulated variable mode.
5.
Move the drive until the working ports are completely exhausted.
6.
Switch off the power supply.
7.
Disconnect the electrical and pneumatic connections.
8.
Remove the positioner
è
5 Assembly.
10 Technical data
10.1
General data
General data
Design Digital, electropneumatic positioner
Mode of operation
CMSH-...-S-... Single-acting
CMSH-...-D-... Double-acting
CMSH-...-SD-... Single-acting/double-acting, switchable
Design features
CMSH-...-SA-... Safety position: Fail Safe - exhaust working port (2)
CMSH-...-DA-... Safety position: Fail Safe - exhaust working port (2), pressurise
working port (4)
CMSH-...-DC-... Safety position: Fail in Place - close working port (2) and working
port (4)
Mounting position
CMSH-... Any
Type of mounting
CMSH-...-VDI1-... With accessories in accordance with VDI/VDE 3845
CMSH-...-VDI2-... With accessories in accordance with VDI/VDE 3847-2
