Commissioning
59
Menu option Description
Configuration reset This function irrevocably resets the device settings to the
delivery status. It does not reset counter readings.
Device configuration A summary of the current device configuration is displayed in
this area.
Tab. 77: ‘Service’ menu
7.2.8 ‘Diagnosis’ menu
The configuration of diagnostic functions and the assignment of an NAMUR status signal to a moni-
toring function can only be performed via EDD and DTM.
Menu option Description
Activation Functions for extended monitoring and diagnostics can be acti-
vated in this area. Corresponding messages are not generated
until after activation.
Monitoring can be activated for the following variables. Multiple
selections are possible:
–
Supply pressure
–
Control deviation
– Dist. actuator
– Direct. actuator
–
Moves actuator
– Dist. armature
– Direct. armature
–
Moves armature
– DI triggered ctrl.
è
7.2.8.1 Activation
Counter The current counter readings are displayed in this area. In addi-
tion, resettable counters can be reset here.
If a counter reaches its threshold value and the associated moni-
toring function is activated, a message is output.
è
7.2.8.2 ‘Counter’ menu
Partial stroke test The Partial Stroke Test can be executed and its status called up in
this area.
è
7.2.8.3 ‘Partial stroke test’ menu
Tab. 78: ‘Diagnosis’ menu
