Commissioning
57
Value Description
180° —
270° —
Tab. 73: Display Orientation
7.2.5 ‘Initialization’ menu
The positioner is not initialised in delivery status.
It must be initialised in the following cases:
– During commissioning
–
After changes in the system structure
– After reset to factory settings
The permissible stroke range and the controller parameters are determined during initialisation. This
involves both end positions being approached in succession independently of the pending setpoint
value.
The progress of the initialisation is shown on the display during the initialisation process. A running
initialisation can be cancelled with the upper key.
After successful initialisation, the display briefly shows the ‘Initialisization successful’ message. The
symbol for a missing initialisation in the process views then disappears
è
Tab. 6 Status and informa-
tion in the information area.
The control parameters can be adapted and, if necessary, optimised in the ‘Control’ > ‘User parame-
ters’ menu
è
7.2.4.2 Control.
7.2.6 ‘Identification’ menu
Menu option Description
Device Device-specific information is displayed in this area.
è
7.2.6.1 Device
Operation unit The description of the operating unit is displayed in this area.
è
7.2.6.2 Operation unit
Tab. 74: ‘Identification’ menu
7.2.6.1
Device
Device-specific information is displayed in this area. These parameters cannot be changed.
