Message Criterion NAMUR
status
1)
Message ID
Test interval exceeded Time since last PST
> T_interval + Tol_interval
1095
Movement or manoeuvre duration is too
long in relation to the reference PST
Fact_duration < ratio < 2 *
Fact_duration
1096
1) Factory setting
Tab. 85: Additional messages for Partial Stroke Test
7.3 Completion of commissioning of the CMSH-...
•
Place the housing cover on the positioner and tighten the 4 housing cover screws.
–
Make sure that the seal is positioned correctly.
– Tightening torque: 1 Nm ± 15%
8
Malfunctions
8.1
Fault description
The error messages are shown on the display according to priority
è
4.1.3.3 Message views.
Every message has a unique number (ID) and is permanently allocated to a predefined message
group. This facilitates troubleshooting and classification in the evaluation.
The message groups are based on the possible sources of error of the NAMUR recommendation NE
107.
Message group ID Context
Drive 1 … 255 Drive, volumetric flow amplifier
Configure 257 … 511 Mounting and commissioning
Electronics 513 … 767 Electronics
Operating conditions 769 … 1023 Specified operating conditions
Process 1025 … 1279 Control, Partial Stroke Test
Sensor 1281 … 1535 Position sensor, position signal
Other 1537 … 1791 Manual operation and other messages
Tab. 86: Allocation of message numbers to message groups
8.2
Messages
Representation of messages on the display
The message text is shown in abbreviated form on the display.
