Technical data
General data
Measuring principle of the displacement encoder
CMSH-S-... Potentiometer
Sensing range of the displacement encoder
CMSH-S-... 0 … 115°
Display
CMSH-... LC display, 90° rotatable via software
Setting options
CMSH-... Via LC display and operating buttons
Tab. 88: General data
10.2 Pneumatic data
Pneumatic data
Operating pressure
CMSH-... 1.4 … 8 bar
Operating medium
CMSH-... Compressed air in accordance with ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium
CMSH-... Lubricated operation not possible
Air output at ∆p = 6 bar
CMSH-...S-... single-acting 380 l/min
CMSH-...D-... double-acting 270 l/min
Pneumatic port
CMSH-...-G14-... G 1/4
CMSH-...-N14-... 1/4 NPT
Connection for pressure gauge
CMSH-...-G14-...-V-... G 1/8
CMSH-...-N14-...-V-... 1/8 NPT
Tab. 89: Pneumatic data
10.3
Electrical data
Analogue input AI
Terminals +11/-12
Nominal signal range 4 … 20 mA with HART
