Commissioning
61
Option Value
range
Description Related
Message
Moves actuator Application-specific monitoring of the total
travel counters, changes in direction and
movements for the drive and the process
valve is activated with these options.
If a counter exceeds the threshold assigned
to it, a message is generated. The current
values of the counters are displayed under
the ‘Counter’ menu item and can also be
reset there
è
7.2.8.2 ‘Counter’ menu.
Factory setting: inactive
active,
inactive
Message ID: 0156,
factory setting:
threshold number of
movements of drive:
500,000
Dist. armature active,
inactive
Message ID: 1174,
factory setting: total
process valve travel
threshold: 50,000,0
00%
Direct. armature active,
inactive
Message ID: 1187,
factory setting:
threshold number
of direction changes
for process valve:
500,000
Moves armature active,
inactive
Message ID: 1184,
factory setting:
threshold number
of movements of
process valve:
500,000
DI triggered ctrl. active,
inactive
Digital input monitoring is activated in this
area. If control is requested via the digital
input via an active function, a message
is generated. Since the externally applied
setpoint value is ignored in this case,
there is usually a deviation between the
external setpoint position specification and
the actual position.
Factory setting: inactive
Message ID: 1557,
factory setting: sub-
stitute value for the
setpoint position
Message ID: 1558,
factory setting:
request for end posi-
tions
Tab. 79: Activation
