2. Installation
2−15
Festo P.BE−CPX−CEC−EN en 1004a
1 Folding cover
with inspection
window
2 Clamp strap
for screened
connection
1)
3 Protective cap if
connection is not
used
4 CAN bus
outgoing (OUT)
5 CAN bus
incoming (IN)
6 SUB−D plug
1)
1)
connected
capacitively
V+
GND
H L
SLD
V+
GND
H L
SLD
21
3
4
56
Fig.2/4: CA N bus plug from Festo, type FBS−SUB−9−B U−2x5POL−B
