2. Installation
2−16
Festo P.BE−CPX−CEC−EN en 1004a
Further connection possibilities for the CAN bus
with adapters
Caution
· Make sure of the correct polarity when you connect the
CAN bus interface.
· Connect the screen.
There are further ways of connecting the CAN bus with
adapters, which can be ordered separately from Festo. These
adapters and additional accessories can be found under:
è www.festo.com/catalogue
M12 adapter 5−pin (protection class IP65),
type FBA−2−M12−5POL
Screw terminal adapter 5−pin (protection class IP20),
type FBA−1−SL−5POL
