B. Ethernet/IP O bjects of the CPX-FB32
B-5
Festo P.BE-CPX-FB32-EN en 1111a
Object class Instances Name Type
101
d
1 ... 48 General module parameter object
(Generic Parameter Object)
CPX specific:
parameter
102
d
1 ... 48 Discrete Input Object CPX specific:
inputs/outputs
103
d
1 ... 48 Discrete Output Object
104
d
1 ... 48 Analogue Input Object
105
d
1 ... 48 Analogue Output Object
106
d
1 ... 48 Function Input Object
107
d
1 ... 48 Function Output Object
108
d
1 ... 48 Discrete Input Force State Object CPX specific:
force, fault, idle
mode
109
d
1 ... 48 Discrete Input Force Mode Object
110
d
1 ... 48 Discrete Output Force State Object
111
d
1 ... 48 Discrete Output Force Mode Object
112
d
1 ... 48 Discrete Output Fault S tate Object
113
d
1 ... 48 Discrete Output Fault Mode Objec t
114
d
1 ... 48 Discrete Output Idle State Object
115
d
1 ... 48 Discrete Output Idle Mode Object
Tab. B/3: Overview of EtherNet/IP objects of the CPX-FB32 – Part 2
