3.2.1 CPX-specific LEDs
PS (power system) – power sensor/logic supply
LED (green) Sequence Status Meaning / error handling
LED lights up
ON
OFF
No error. Operating
voltage/sensor supply
applied
–
LED flashes
ON
OFF
Operating voltage/sensor
supply outside the
tolerance range
Eliminate undervoltage
ON
OFF
Internal fuse for the
operating voltage/sensor
supply has responded.
1. Eliminate short circuit/overload on
module side.
2. Depends on the parameterisation
of the module (module parameter):
• The sensor supply voltage will be
switched on again automatically
after the short circuit has been
eliminated (default)
• Power Off/On is necessary
LED is off
ON
OFF
The operating voltage/
sensor supply is not
applied
Check the operating voltage
connection of the electronics
PL (power load) – power load supply (outputs/valves)
LED (green) Sequence Status Meaning / error handling
LED lights up
ON
OFF
No error. Load voltage
applied
None
LED flashes
ON
OFF
Load voltage at the system
supply or additional supply
outside the tolerance
range
Eliminate undervoltage
