2. Commissioning
2-36
Festo P.BE-CPX-FB32-EN en 1111a
2.3.3 Parameterisation via software (method 2a)
With the CPX Maintenance Tool (CPX-FMT), you can
parameterise the CPX terminal with a PC via Ethernet.
The CPX-FMT is available in the internet at:
– www.festo.c om/fieldbus.
2.3.4 Parameterisation with the Handheld (method 2b)
The Handheld offers menu-orientated access to
parameterisatio n without configuration software.
Information on operating the Handheld can be found i n the
relevant description.
Note
The last parameterisatio n received i n the CPX terminal is
always valid.
The CPX terminal can only be parameterised i f the system
parameter “System start” has the setting “System start with
default parameterisatio n and current CPX expansion”.
In this case, the standard parameter settings are valid in the
CPX terminal after Pow er On.
Note
If the system parameter “S ystem start” has the setting
“System start with saved parameterisation and saved CPX
expansion”, modified parameter setti ngs in the CPX
terminal will become valid immediately after Power On.
