2. Commissioning
2-4
Festo P.BE-CPX-FB32-EN en 1111a
2.1.1 Ascertaining the address range
Address assignment of the modules
Electric modules
The individual modules are displayed with their identifier on
the handheld. In the case of the I/O modules, the identifier is
also shown in the LED viewing window. With the aid of this
identifier, you can read the type of module and therefore the
number of inputs and outputs occupied by the module.
Electric modules
Type Module
identifier
1)
Assigned addresses
Inputs Outputs
Fieldbus node FB32 CPX-FB32 FB32-... – –
Digital 4-input module CPX-4DE 4DI 4E
2)
–
Digital 8-input module CPX-8DE 8DI 8I –
Digital 8-input module with channel
diagnostics
CPX-8DE-D 8DI-D 8I –
Digital 16-input module CPX-16DE 16DI 16 I –
Digital 16-input module with channel
diagnostics
CPX-16DE-D 16DI-D 16 I –
Digital 8-input module n-switching CPX-8N DE 8NDI 8I –
Digital 4-output module CPX-4DA 4DO – 4O
2)
Digital 8-output module CPX-8DA 8DO – 8O
Digital 8-output module, h igh-current
variant
CPX-8DA-H 8DO-H – 8O
1)
Module identification in Handheld
2)
8 bits are always occupied
Tab. 2/1: Overview of electric CPX modules (part 1)
