2. Commissioning
2-5
Festo P.BE-CPX-FB32-EN en 1111a
Electric modules
1)
Type Module
identifier
Assigned addresses
Inputs Outputs
Digital multi I/O module CPX-8DE-8DA 8DI/8DO 8I 8O
Analogue 2-input module CPX-2AE-U-I 2AI 32 I –
Analogue 4-input module CPX-4AE-U-I 4AI 64 I –
Analogue 4-input module CPX-4AE-I 4AI-I 64 I –
Analogue 4-input module
(temperature module)
CPX-4AE-T 4AI-T 32/64 I
2)
–
Analogue 2-output module CPX-2AA-U-I 2AO – 32 O
CP interface CPX-CP-4-FB CPI 128 I
3)
128 O
3)
Front End Controller CPX-FEC FEC 64/128 I
4)
64/128 O
4)
1)
Additional modules in preparation
2)
Number of inputs switchable between 2 and 4
3)
Maximum number (actual allocation de pends on the string allocation)
4)
With the CPX-FB32, switchable via DI L switches (see 1.2.2)
Tab. 2/2: Overview of electric CPX modules (part 2)
The address assignment within the individual I/O modules
can be found in the manual for the I/O modules.
Details on the CP i nterface can be found i n the manual for th e
CP i nterface.
