Pneumatic modules and pneumatic interfaces
The following table shows the number of output addresses
occupied by the pneumatic modules:
Pneumatic interfaces
1)
Type Module
identifica-
tion
2)
Assigned addresses
Inputs Outputs
Pneumatic interface for M PA-S valves
(type 32)
VMPA-F B-EPL-... – – –
Pneumatic interface for M PA-F valves
(Type 33)
VMPAF-FB-EPL-... – – –
Pneumatic interface for M PA-L valves
(Type 34)
VMPAL-EPL-CPX – – –
Pneumatic interface for CPA valves
(type 12) with setting:
3)
– 1 ... 8 valve c oils
– 1 ... 16 valve coils
– 1 … 2 4 v alve coils (22 can be used)
CPX-GP-CPA-10
CPX-GP-CPA-14
CPA10/14 –
8O
16 O
24 O
Pneumatic interface for Midi/Maxi
valves (type 03) with setting:
2)
– 1 ... 8 valve c oils
– 1 ... 16 valve coils
– 1 ... 24 valve coils
– 1 … 32 valv e coils (26 can be used)
CPX-GP-03-4.0 TYPE3 –
8O
16 O
24 O
32 O
Pneumatic interface for VTSA
pneumatic (ISO, Type44)
2)
and
VTSA-F pneumatic
– 1 ... 8 valve c oils
– 1 ... 16 valve coils
– 1 ... 24 valve coils
– 1 ... 32 valve coils
VABA-10S6-x1 ISO plug-in or
type 44
3)
–
8O
16 O
24 O
32 O
1)
Additional interfaces in preparation
2)
Module identification in Handheld
3)
Setting with DIL switches in the pneumatic interface (see description, CPX-EA modules).
Tab. 2/3: Overview of pneumatic interfaces
