2. Commissioning
2-7
Festo P.BE-CPX-FB32-EN en 1111a
Pneumatic modules
1)
Type of
electronic
module
Module
identifica-
tion
2)
Assigned addresses
Inputs Outputs
MPA1 pneumatic module
(type 32, 33) without galvanic
isolation
VMPA1-FB-EMS-8 MPA1S – 8O
MPA1 pneumatic module
(type 32, 33) with galvanic isolation
VMPA1-FB-EMG-8 MPA1G – 8O
MPA2 pneumatic module
(type 32, 33) without galvanic
isolation
VMPA2-FB-EMS-4 MPA2S – 4O
3)
MPA2 pneumatic module
(type 32, 33) with galvanic isolation
VMPA2-FB-EMG-4 MPA2G – 4O
3)
MPA1 pneumatic module
(type 32, 33) without galvanic
isolation with diagnostic function D2
VMPA1-FB-EMS-
D2-8
MPA1S-D – 8O
MPA1 pneumatic module
(type 32, 33) with galvanic isolation
with diagnostic function D2
VMPA1-FB-EMG-
D2-8
MPA1G-D – 8O
MPA2 pneumatic module
(type 32, 33) without galvanic
isolation with diagnostic function D2
VMPA2-FB-EMS-
D2-4
MPA2S-D – 4O
3)
MPA2 pneumatic module
(type 32, 33) with galvanic isolation
with diagnostic function D2
VMPA2-FB-EMG-
D2-4
MPA2G-D – 4O
3)
1)
Additional modules in preparation
2)
Module identification in Handheld
3)
8 bits are always assigned
Tab. 2/4: Overview of pneumatic modules MPA-S and MP A-F
