2. Commissioning
2-29
Festo P.BE-CPX-FB32-EN en 1111a
2.3 Parameterisation
Caution
A different parameterisation will result in different
characteristics. Check especially when replacing CPX
terminals to see which settings are necessary and make
sure that these are restored (e.g. in the start-up phase by
the higher-order PLC/IPC).
The CPX terminal is supplied from the factory with preset
parameters.
The system reaction of the CPX terminal can be adapted to
the relevant application. You can set the reaction of the CPX
terminal as well as the reaction of individual modules and
channels through parameterisation. A distinction is made
between the following parameterisatio ns:
– System parameterisation, e.g.: switching off of
malfunction messages, setting of reaction times, etc.
– Module parameterisation (module- and channel- specific),
e.g.: monitoring, settings in case of error, settings for
Forcing.
– Parameterisatio n of the diagnostic memory.
A detailed description of the individual parameters as well as
fundamentals for application can be found in the CPX system
description (P.BE-CPX-SYS-...) The module parameters that
are available for the various modules can be found in the
description of the relevant module (e.g. Description of the
CPX pneumatic i nterfaces and CPX I/O modules
(P.BE-CPX-EA-...).
