2.3.5 Parameterisation via the PLC user p rogram (method 3)
Program-controlled access to parameters is made via the
“Explicit Message” programming. The addresses of the
EtherNet/IP Object Model required for this can be found in
Appendix B. Information on programming this data
transmission can be found in the manual for your controller.
In order to address the CPX terminal with FB32 you will
require the following Object descriptions:
Detailed Object descriptions can be found in Appendix B.1.
Object
classes
Instances
(dec.)
Attri-
butes
(dec.)
Name
4
d
100 ... 102 - Assembly Object
102
d
1 ... 48 1, 2 Modificatio n digital inputs, Object
103
d
1 ... 48 1 ... 6 Modification digital outputs, Object
104
d
1 ... 48 1, 2 Modificat ion analogue inputs, Object
105
d
1 ... 48 1 ... 6 Modification analogue outputs, Object
106
d
1 ... 48 1, 2 Modification input words of technology module, Object
107
d
1 ... 48 1 ... 6 Modification output words of technology module, Object
132
d
1 1 ... 37 System Object (Global System Object)
133
d
1 1 ... 3 Status and Diagnostic Object
134
d
1 ... 40 1 ... 12 Diagnostic Trace Object
135
d
1 1 ... 13 Diagnostic Trace Status Object
Tab. 2/15: Overview of Object classes for EtherNet/IP (operating mode Remote I/O)
