2. Commissioning
2-38
Festo P.BE-CPX-FB32-EN en 1111a
Object
classes
Instances
(dec.)
Attri-
butes
(dec.)
Name Type
136
d
1 1, 2 SlaveSizeObject
(only Remote Controller)
SINT
Tab . 2/16: Object class for EtherNet/IP in operating mode Remote Controller
2.3.6 Parameterisation with EDS files (method 4)
This method of parameterisation is only possible if your
configuration program supports parameterisation via EDS.
The EDS files of the CPX terminal must be contained in the
EDS library.
The CPX-EDS Version 1.2 is used only for identification of the
CPX-FB32 in the network.
