2. Commissioning
2-23
Festo P.BE-CPX-FB32-EN en 1111a
Note
From CPX-FB32 Revisio n 17, the “Major Revision” was
raised from 1 to 2. F or “Major Revision” 2, a new EDS file
must be used or the corresponding setting made in the
controller.
Nodes with “Major Revision” 2 are downward compatible
with “Major Revision” 1
The EDS file suitable to your CPX-FB32 can be determined
and downloaded at www.festo.com in the Festo Support
Portal.
Note
If the station features are entered manually, individual
parameterisatio n of the CPX terminal is not possible.
When the EDS library has been expanded, the CPX terminal is
entered in the station list as a possible EtherNet/IP station.
It can now be added to a network.
2.2.2 Overview of configuration on the EtherNet/IP
When the station features have been configured
(e.g. by installatio n of the EDS file), the follow ing steps are
required for parameterisation (depending on the
configuration program):
1. Install your CPX terminal and set the network addressing
according to section 1.3.3.
2. Create a connection to an EtherNet/IP station.
With RSLogix, use for this the profile
“Generic Ethernet Device”.
