3. Diagnostics
3-5
Festo P.BE-CPX-FB32-EN en 1111a
3.2 Diagnostics via LEDs
L EDs for diagnosing the CPX terminal are available on the
fieldbus node as well as on the individual modules.
The meaning of the L EDs on the electric modules can be
found in the description for the relevant module.
LE Ds on the fieldbus node CPX-FB32
The LEDs on the cover indicate the operating status of the
CPX fieldbus node.
1 CPX-specific L EDs
PS: Power System
PL: Power L oad
SF: S ystem F ault
M: Modify
2 EtherNet/
IP-specific LEDs
MS: Module Status
NS: Network S tatus
IO: I/O Status
TP: Link/Traffic
PS
PL
SF
MS
NS
IO
M
1
2
PS
PL
SF
MS
NS
IO
M
TP
TP
Fig. 3/1: LEDs on the CPX fieldbus node
