2. Commissioning
2-25
Festo P.BE-CPX-FB32-EN en 1111a
2.2.4 Configuration with R SLogix5000
With the help of the CPX Festo Maintenance Tool (CPX-FM T),
it is also possible to export the configuration of a CPX
terminal with EtherNet/IP bus node into an RSL o gix5000
project (see section 2.3.2).
1. Click in RSLogix5000 in the “I/O Configuration” on the
right on the Ethernet/I P bridge and select “New Module”:
