2. Commissioning
2-22
Festo P.BE-CPX-FB32-EN en 1111a
Entering station properties manually
When an EDS file is installed, the following information about
the EtherNet/IP station is added to the EDS library.
This information can also be entered manually if the CPX
terminal is to be operated with the parameter settings preset
at the factory.
Information
Description
Vendor name Festo Corporation
Vendor ID 26
D
1A
H
Device type 12
D
C
H
Product code (depends on
operating mode)
– Remote I/O
– Remote Controller
13002
D
32CA
H
13003
D
32CB
H
Major Revision 2
1)
Input size / output size Depends on CPX equipment
Product name CPX-FB32
Catalogue number 541302
Extended Ethernet/IP station features
Request Packet Interval (RPI) ≥10ms
Connections:
– Total of all c onnections
– Exclusive Owner
– Input only
–Listenonly
Max. 32
Max. 1
Max. 32
Max. 31 ( There has to be
simultaneously at least 1
Excl.Owner or input only
connection)
1)
From CPX-FB32 Revision 17
Tab. 2/13: S tati o n features
